TIAGO

525 / 1002

BRAKES
6
BRAKE NOISE
. CAUSES REMEDY
1
Glazed shoe linings or foreign matters stuck
on linings
Repair or replace shoe linings
2 Worn or distorted shoe linings Replace shoe linings or pads
3 Loose front wheel bearings Replace wheel bearing
4
Distorted backing plate or loose mounting
bolts
Replace or retighten
5 Broken / missing anti-rattle clip Replace
EXCESSIVE PEDAL TRAVEL
. CAUSES REMEDY
1 Partial brake system failure Replace Master cylinder assembly complete.
2 Air in system (pedal soft/spongy) Bleed and top up with recommended brake fluid
3 Soft or bulging hose Replace the hose
4 Excessive clearance between lining and
Check auto adjuster mechanism drum in rear
brakes due to malfunctioning of auto adjusters.
5 Lining pad knock back caused by
Adjust or replace faulty parts as necessary loose
or worn wheel bearing or other related parts
6 Insufficient fluid in master cylinder reservoir
Fill reservoir with approved brake fluid. Check for
leak and air in brake system. Checks warning light
bleed system if required.
7 Bend brake shoes or shoes worn out Replace brake shoes.
BRAKE WARNING LIGHT LIGHTS AFTER ENGINE START
. CAUSES REMEDY
1 Parking brake lever in applied
Release parking brake and check that condition
brake warning light turns off
2 Brake fluid level very low. Add brake fluid of correct specification
3 Leakage of brake fluid
Investigate and correct leaky point. Add brake
fluid
4 Brake warning light circuit faulty Repair circuit
