BRAKES
4
6.3 TIGHTENING TORQUES
SR.NODESCRIPTION
TORQUE (Kg-m)
1
Booster mounting bolt to firewall
2.0 – 2.5
2
Mounting nuts of master cylinder to Booster
1.0 – 1.6
3
All brake pipe lines joints (coupling nut)
1.4 – 1.8
4
Front caliper, retaining bolt to steering knuckle
7.0 – 8.0
5
Front caliper carrier retaining bolt
2.2 – 3.2
6
Front brake hose mounting (banjo) to caliper
2.3 – 2.5
7
Front caliper bleed screw
0.7 – 1.0
8
Front brake disc holding CSK screw
0.6 – 0.8
9
Rear axle castle nut
15.5 – 19.5
10
Rear brake assembly to Twist beam flange
4.2 – 5.0
11
Rear wheel cylinder mounting to brake plate
1.0 – 1.2
12
Rear wheel cylinder bleed screw
0.6 – 0.9
13
Wheel mounting nuts
7.9 – 8.1
14
Parking brake cable clamps to Cable mtg. Bracket assembly
0.8 – 1.0
15
Cable mtg. Bracket assembly to Body
0.8 – 1.0
16
Parking brake lever mounting to Floor
0.8 – 1.0
17
Cable guide to floor
0.8 – 1.0
18
Parking brake cable clamp to twist beam bracket
0.8 – 1.0
19
Vacuum line clamps
0.8 – 1.0
20
ABS unit mounting bracket to body
0.8 – 1.0
