DRIVETRAIN-TA65 Star
43
22. Tilt slightly the assembly (engine and
transaxle) and remove the starter motor.
23. Remove B mount bracket from transaxle
housing.
24. Remove clutch housing mounting bolts and
take out the transaxle.
25. Remove clutch release bearing from input
shaft.
26. Lift and support the engine assembly properly
using engine holding stand (2871 5890 3211)
on vehicle.
