422 / 1002
DRIVETRAIN-TA65 Star
40
SR.
NO.
DESCRIPTION
01
LAYSHAFT (65/16)
02
CYLINDRICAL ROLLER BRG
(L/S);FAG
02
CYLINDRICAL ROLLER BRG.(L/S);SKF
02
CYLINDRICAL ROLLER BEARING
(L/S) (ABC)
02
CYLINDRICAL ROLLER BEARING
(L/S);NRB
02
OFFER DRG.CYLD.ROLLER BRG.(L/S
FRT.END)
02
CYLINDRICAL ROLLER BEARING
(TEXSPIN)(ADAPTOR SHAFT
03
BUSH (LAYSHAFT)
04
CIRCLIP (LAYSHAFT)
04
CIRCLIP (LAYSHAFT)
04
CIRCLIP (LAYSHAFT)
04
CIRCLIP (LAYSHAFT)
05
1ST GEAR LAYSHAFT (3.83)
06
SYNCHRO CONE;OUTER;1ST/2ND
06
SYNCHROCONE OUTER (1st/2nd)
BORG-WARNER
07
INTERMEDIATE CONE 1ST/2ND (INA)
07
INTERMEDIATE CONE (1st/2nd)
BORG-WARNER
07
INTERMEDIATE CONE;1ST/2ND
SPEED
08
INNER CONE 1ST/2ND WITH
CARBON LINING
08
INNER CONE (1st/2nd) BORG-
WARNER
09
ENGAGING GEAR 1ST/2ND (SINT
SOFT VER.)
10
SLEEVE (1/2 SYNCHRO)
11
BALL 5.556DIA-GRADE 20 IS2898
12
SPRING (SYNCHRO)
13
CARRIER (1/2 SPEED)
14
REV.GEAR/SHIFTER SLEEVE
1ST/2ND SPEED
SR.
NO.
DESCRIPTION
15
2ND GEAR LAYSHAFT (2.105)
16
3RD GEAR LAYSHAFT (RATIO 1.27)
17
SYNCHROCONE (3RD/4TH & 5TH
SPEED)
18
ENGAGING GEAR 3RD/4TH SPEED
19
SHIFTER SLEEVE 3RD/4TH SPEED
20
CARRIER (3/4/5 SPEED)
21
SYNCHRO RING (4/5 SPEED);
SPLINED
22
PLATE (4TH/5TH SPEED GEAR)
23
4TH GEAR LAYSHAFT (RATIO 0.88)
24
SPACER (L/S)
25
BALL BRG.WITH SNAP RING (L/S
REAR);FAG
25
BALL BRG.WITH SNAP RING (L/S
REAR) NRB
25
ASSY.BRG.WITH SNAP RING (L/S
REAR END)
25
BALL BRG.WITH SNAP RING (L/S
REAR);TISCON
26
LOCK PLATE (LAYSHAFT BRG.)
27
SPACER (REVERSE IDLER GEAR)
28
BUSH (5TH GEAR L/S) NRB
29
NEEDLE CAGE (5TH GEAR L/S); NRB
30
5TH GEAR LS (0.674) LASER WELD
VERSION
30
5TH GEAR LAYSHAFT (RATIO 0.674)
31
ENGAGING GEAR 5TH SPEED
32
SHIFTER SLEEVE (5TH SPEED)
33
LOCK PLATE (5TH SPEED GEAR)
34
LOCK NUT (LAYSHAFT/INPUT SHAFT)
35
SOCKET HEAD CAP SCREW
36
BALL BEARING (I/S FRONT
END);TISCO
