1.05L REVOTORQ ENGINE
43
FUEL INJECTION EQUIPMENT :
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
HP Line Clamp on Cylinder Head Cover
(Hex Fl Screw M6X16)
1+0.2
02
Assembly Fuel Pressure Line
(HP Pump to Rail)
03
Cap Connector for Fuel Pressure Line
(M14X1.5)
2.5+0.3
04
Assembly Back Leak Hose
05
Fuel Rail on Bearing Frame
(Hex Fl Bolt M8X25) (Qty - 2)
2+0.3
06
Assembly Fuel Rail
07
Cap Connector for Fuel Pressure Line
(M14X1.5)
•
3+0.3
08
Assembly Fuel Pressure Line
(Fuel Rail to Injector)
Note :
•
This Symbol indicates critical tightening torque.
