234 / 1002
1.05L REVOTORQ ENGINE
23
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
06
Oil Pump Assembly
07
Crankshaft Oil Seal (Front)
08
Oil Pump on Cylinder Crankcase
(Hex Fl Screw M6X25) (Qty - 9)
1+0.2
09
Gasket (Oil Pump Strainer)
10
Spring Washer
11
Assembly Strainer to Oil Pump
(Cap Screw M6X16) (Qty - 2)
1+0.2
12
Assembly Strainer (For Oil Pump)
13
Gasket (For Piston Cooling Nozzle)
14
Piston Cooling Nozzle
15
Piston Cooling Nozzle Mounting
(Cap Screw M5X16) (Qty - 3)
0.8+0.2
16
Assembly TC Oil Return Line
17
TC Oil Return (Both Side)
(Hex Fl. Bolt M6X20) (Qty - 4)
1+0.2
18
Gasket (Adaptor Crankcase to Oil Cooler)
19
Adaptor (Crankcase to Oil Cooler)
20
Low Oil Pressure Switch
3+0.5
21
Assembly Oil Cooler
22
Adapter Assembly, Oil Cooler (M20X1.5)
3.8+0.5
23
Oil Filter Assembly (M24X1.5)
2+0.3
24
Oil Cooler adaptor on Crankcase
(Hex Fl Bolt M6X55) (Qty - 5)
1+0.2
25
Gasket (Tube to TC)
26
Pipe Union Bolt (For Oil Feeder & Boost
Sensor Line) (M10) (Qty - 1)
2+0.3
