230 / 1002
1.05L REVOTORQ ENGINE
19
ENGINE MOUNTING SYSTEM :
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Lifting Hook (Rear)
02
Hex FL Screw M8 X 20
2+0.3
03
Bracket (Engine Mounting Arm)
04
Hex FL Bolt M8 X 80
•
2+0.3
05
Hex FL Bolt M8 X 35
•
2+0.3
06
For engine mounting arm on engine
mounting bracket (Stud BM10 X 45)
•
4+0.5
07
Hex FL Screw M8 X 20
2+0.3
08
Lifting Hook (Front)
Note :
•
This Symbol indicates critical tightening torque.
