284 / 310
CLUTCH
30
3.1.2.3.5 SINGLE MASS FLYWHEEL (ON
VEHICLE)
REMOVAL
1. Disconnect battery connection.
2. Remove stone guard from the vehicle.
3. Remove the starter motor
(For procedure refer
Electrical section.)
4. Lower the gearbox from the vehicle.
(For
procedure refer gearbox removal in Gearbox
section.)
5. Remove the clutch disc with clutch cover
assembly.
(For procedure refer clutch cover
assembly removal procedure in this section.)
6. Loosen and remove mounting bolts
(8 Nos.)
and separate the flywheel assembly from the
engine.
FITMENT
For fitment follow the reverse procedure of
removal.
