ARIA

ENGINE

CAUTION

Care should be take that this liquid gasket should not

spill on the camshaft bearing area

11.Assemble the rear timing cover and tighten the

mounting boils

12.Lock the cam shaft using cam shaft locking plate.

(Part no. 2653 5890 06 05)

13.Assembly the cam shaft gear.

14.Remove the cam shaft locking plate

(Part no.

2653 5890 06 05).

15.Assemble cylinder head cover

Tightening torque sequence of cylinder head.
