ENGINE COMPONENTS
30
16. Remove the bolts of exhaust assembly
support bracket from gear box housing.
17. Remove the all three nuts of silencer pipe
flange from exhaust system assembly.
18. Remove the clinch nuts (nos. 4) of exhaust
assembly from cylinder head studs.
19. Remove the exhaust gasket from cylinder
head studs.
Installation:
CAUTION
Check the threads of cylinder head stud if found
damaged change it. (Apply thread locker
‘Antiseze Thread Compound Qualilub-1001’).
1. Locate and fix the exhaust gasket on cylinder
head studs.
2. Locate and align the exhaust assembly to
cylinder head studs, silencer pipe flange and
exhaust assembly support bracket to gear box
housing carefully securing body.
