ENGINE COMPONENTS
28
6. Remove the floor mat.
7. Loosen the all six wing bolts of engine access
cover and remove it.
8. Remove the upper side bolts of rear bumper.
9. Remove the bolt located at bottom from both
side of the bumper.
10. Remove the wheel arch from both side by
removing screws (Nos. 4 each side) securing
wheel arch to the body.
