STEERING
8
Align it such that the ‘T’ – emblem and spokes
are aligned properly and refit the steering wheel.
F. STEERING WHEEL PLAY
1. Position the front wheels straight ahead and
switch OFF the engine.
2. Turn the steering wheel to measure rotation/travel
of the steering wheel to left and right without turn-
ing the front wheels.
The steering wheel play value is “a” = 25 to 30 mm.
If the play is within the specified limit the steer-
ing linkages are OK.
If the steering wheel free play is not within the
speciation, inspect the following areas & replace
the components if found defective.
a. Tie rod end ball stud for wear / looseness.
b. Lower arm ball joint for wear / looseness.
c. Steering shaft joint for wear / looseness.
d. Steering pinion or rack gear for wear / loose-
ness.
e. Each component of steering system for loose-
ness.
f. Strut upper cup for wear
