ZEST AND BOLT - page 786

BODY
12
9.5 SEATS
9.5.1 REMOVAL OF FRONT SEAT:
1. Slide the Front Seat Backwards & Remove
Front Inner Fastener.
2. Remove Front Seat Front Outer Fastener.
3. Push Front Seat at Front.
4. Slide the seat towards front & Remove Front
Seat Rear Inner Fastener.
5. Remove Front Seat Rear Outer Fastener.
6. Remove seat belt electric connection.
7. Remove Front Seat.
REFITMENT OF FRONT SEAT:
1. Locate The Front Seat Properly.
2. Refit Front Seat Rear Outer & Inner
Fasteners.
3. Slide Front Seat Backwards.
4. Refit Front Seat Front Inner & Outer
Fasteners.
5. Fit the Front Seat.
