Revotron 1.2T
31
Exhaust Manifold :
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(Kgfm)
1 Heat Shield Assembly (Exhaust Manifold)
2 Exhaust Manifold
3 Gasket (Exhaust Manifold)
4 Support Bracket (CCC at middle)
5 Hex. FL Screw M8X18 (Support Bracket)
2
6 Hex. FL Screw M8X18 (CCC Support)
2
7 Support Bracket (CCC at Rear)
8 Hex. Flange M8 Nut (Support Bracket)
2
9 Hex. FL Screw M8X18 (Front)
2
10
Hex. FL Screw M8X18 (CCC Support Bkt
rear)
2
11 Assembly Close Coupled Catcon
12 Hex. FL Nut AM8 (CCC Mounting)
3
13 Self Locking Nut (Exhaust Manifold)
1.9 to 2.1
14 Gasket (Turbocharger to CCC)
15 Hex. FL Nut AM8 (Turbocharger)
3
16 Gasket (Turbocharger Inlet to Ex. Manifold)
17 Turbocharger Assembly
18 Hex. FL Screw M6X18 (Heat Shield Exhaust)
1.5
19 Hex. FL Screw M6X22
1.5
20 Heat Shield Assembly
21 Hex. FL Nut AM6
1.5
22 Bracket (Turbocharger Support)
23 Hex. FL Nut AM6
1.5
