Revotron 1.2T
40
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(Kgfm)
26 Spring Band Clamp (53DX12W)
27 Hose (Intercooler to Intake Manifold)
28 Spring Band Clamp (60DX12W)
29 Hose Assembly (Air Filter to Turbocharger)
30 Hose Clamp
3 - 3.5 Nm
31 Hex. FL Screw M6X30 (Air Filter)
1
32 Rubber Grommet
33 Bracket Air Filter Mounting
34 H/FL Screw M6X12 (Bracket Air Filter)
1
