Cylinder Head :
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(Kgfm)
1 Rocker Spring Seat
2 Spring (Rocker Arm Shaft)
3 Rocker Arm Assembly
4 Screw (Rocker Shaft Holder)
1
5 Rocker Shaft
6 Camshaft
7 Intake Valve
8 Exhaust Valve
9 Valve Guide Seal
10 Spring Seat
11 Valve Spring
12 Valve Spring Retainer
13 Lock Half
14 Adjusting Screw (Rocker Arm)
15 Rocker Nut
2 to 2.5
