Revotron 1.2T
35
Lubrication Pump and Lines :
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(Kgfm)
1 Gasket (For Oil Pump)
2 Oil Pump
3 Hex. Screw M6X25 (Oil Pump)
1
4 Oil Seal (Crankshaft) (Front)
5 Flanged Clinch Nut M6
1
6 Stud CM6X16 (Strainer)
7 Strainer Assembly (For Oil Pump)
8 Gasket (Oil Pump Strainer)
9 Adaptor (For Oil Filter Mounting)
10 Banjo Bolt (Oil Filter Adaptor) (M20 X 1.5)
4
11 Oil Filter Assembly***
See Note 1
12 Adaptor
1.
***Oil Filter fitment procedure :
Apply oil on seal face and screw in until seal touches face.
Tighten further by 3/4 turn.
Do not over tighten.
