Cylinder Head and Cover :
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(Kgfm)
1 Hex. FL Screw M6X22 (Head Cover)
0.8 to 1
2 PCV Valve Assembly
0.18 to 0.29
3 Gasket (Cylinder Head Cover)**
4 Hex. Bolt (Cylinder Head)***
See Note 1
5 Washer
6 Gasket (Cylinder Head)
7 Gasket (Vacuum Pump)
8 Vacuum Pump Assembly
9 H/FL Screw M6X20 (Vacuum Pump)
1.5
10 'O' Ring (Oil Filler Cap)
11 Oil Filler Cap
1.2
1.
***
Sequence for Cylinder Head bolt tightening during engine assembly :
A. Step 1 : Tighten to 3 kgm in the sequence as marked.
Step 2 : Tighten to 5 kgm in the same sequence as marked.
Step 3 : Tighten to 6.5 kgm in the same sequence as marked.
B. Alternatively all screws to be machine tightened simultaneously as per each step shown above.
2. **It is recommended to replace the cylinder head gasket whenever the cylinder head is removed
from cylinder block.
