Revotron 1.2T
25
Cylinder Block :
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(Kgfm)
1 Gasket (Oil Sump)
2 Oil Sump
3 Sealing Washer
4 Drain Plug (M12X1.5)
3.5
5 H/FL Screw M6X14 (Oil Sump)
1
6 Gasket (Rear Cover Crankcase)
7 Rear Cover Crankcase
8 Crankshaft Oil Seal (Rear)
9 Hex. Screw M6X20
1
