Revotron 1.2T
27
Moving Parts :
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(Kgfm)
1 Top Ring
2 Taper Faced Ring
3 Oil Ring
4 Piston Pin
5 Round Wire Circlip
6 Conrod Bush
7 Connecting Rod
8 Upper Bearing Half (Connecting Rod)
9 Lower Bearing Half (Connecting Rod)
10 Bolt (Connecting Rod) (M8 X 1)
4.5
11 Spacer (For Gear Crankshaft)
12 Gear Crankshaft
13 Assembly Vibration Damper Pulley
14 Hex. Bolt (Crankshaft Gear) (M14 X 1.5)
4+60
0
15
Bolt (Gear Crankshaft)(Vibration
Damper)(M8)
2.5
16 Crankshaft
17 Thrust Washer (Lower)
18 Thrust Washer (Upper)
19 Bearing Shell Half (Crankshaft)
20 Bearing Shell Half Lower (Crankshaft)
21 Flywheel
22 Hex. Bolt (For Flywheel) (M10 X 1.5)
5
23 Piston
