DRIVETRAIN C549
15
C Tightening Torque
Sr
No
Fastener Location/Description
Fastener Type
Size
Tightening Torque in
Kg-m
1
Gear selection/engagement lever
Bolt
M 8
2.1~2.6
2
1st and 2nd speed control fork
Bolt
M 6
1.5~1.9
3
3rd and 4th speed control fork
Bolt
M 6
1.5~1.9
4
Reverse control for mounting bracket
Bolt
M 6
8.5~11.1
5
Gearbox casing
Bolt
M 8
2.1~2.6
6
Reverse shaft
Bolt
M 8
2.9~3.6
7
Main and lay shaft rear bearings
retaining plate
Bolt
M 8
2.1~2.6
8
Main and lay shaft ring nuts
Ring nut
M 20
10~12.4
9
5thspeedcontrolfork
Bolt
M 6
1.5~1.9
10
Rear cover
Bolt
M 8
2.1~2.6
11
Main and lay shaft ring nuts
Ring nut
M 20
10~12.4
12
5thspeedcontrolfork
Bolt
M 6
1.5~1.9
13
Rear cover
Bolt
M 8
2.1~2.6
14
Manual gearbox-differential ring gear
Bolt
M 10
7.7~9.2
