DRIVETRAIN C549
24
22.Remove reverse gear sensor connections
23.Remove peripheral bolts holding Transaxle on
the engine.
24. Support the transaxle on top side suitably.
25. Support the Engine by Jack.
26. Remove transaxle.
INSTALLATION OF TRANSAXLE ON THE
VEHICLE
1. Mount the Transaxle assembly on the engine
and tighten the bolts holding Transaxle on the
engine.
2. Fit reverse gear sensor connections.
3. Fit Speed sensor connections.
4. Connect Earthing connections.
