DRIVETRAIN C549
10
(2) CLUTCH CONTROL QUADRAJET
ITEM NO..
DESCIPTION
01
T2 CMC FOR CLUTCH ACTUATION-VALEO
02
HOSE FOR T2 CMC
03
CLUCTH MASTER CYLINDER ASSEMBLY
04
HIGH PRESSURE LINE(NYLON)
05
CLAMP FOR BRAKE AND VACUUM PIPELINES (4.75 TO 9 O)
06
CLAMP FOR HYD. CLUTCH PIPE
07
RUBBER SEAL
08
ASSY BRACKET WELDED T2 CMC
09
BOLT:-DUAL_CLUTCH_SENSOR_SDE_M\S
10
HEX FL SCR M5X12 TS17130-8 8-SS8451S2-Y
11
H FL SCREW M8X18 TS17130-8 8-SS8451S2-Y
12
ASSITANCE GUIDE SEAT TOP
13
COMPRESSION SPRING (FOR CLUTCH ASSITANCE)
14
ASSITANCE SPRING SEAT BOTTOM
15
HEX SCREW M8X25 IS1364P2-8.8-SS8451S2-Y
16
RUBBER STOPPER (CLUTCH PEDAL)
17
NYLOC NUT M10 IS7002-8-SS8451S2-Y
18
BRIGHT WASHER 10 5 IS2016 ST SS8451S2-Y
19
CLUTCH PEDAL RETURN SPRING
20
POIVOT BUSH
