ELECTRICAL
175
B2248 – 11
Right Rear Fog Lamp Circuit – Short to Ground
B2248 – 15
Right Rear Fog Lamp Circuit – Short to Battery or Open Circuit
B2253 – 11
Turn Left Indicator Switch Circuit – circuit short to ground.
B2253 – 12
Turn Left Indicator Switch Circuit – circuit short to battery
B2254 – 11
Turn Right Indicator Switch Circuit – circuit short to ground.
B2254 – 12
Turn Right Indicator Switch Circuit – circuit short to battery
B2217 – 11
Hazard Switch – Short to Ground
B2217 – 12
Hazard Switch – Short to Battery or Open Circuit
B1301 - 11
Driver Door Ajar Switch - Circuit Short to Ground
B1301 - 12
Driver Door Ajar Switch - Circuit short to Battery or Open Circuit
B1308 - 11
Passenger Door Ajar Switch - Circuit Short to Ground
B1308 - 12
Passenger Door Ajar Switch - Circuit short to Battery or Open Circuit
B1306 - 11
Left Rear Door Ajar Switch - Circuit Short to Ground
B1306 - 12
Left Rear Door Ajar Switch - Circuit short to Battery or Open Circuit
B130D - 11
Right Rear Door Ajar Switch - Circuit Short to Ground
B130D - 12
Right Rear Door Ajar Switch - Circuit short to Battery or Open Circuit
B1620 - 11
Other Doors Switch - Circuit Short to Ground
B1620 - 12
Other Doors Switch - Circuit short to Battery or Open Circuit
B162C - 11
Tailgate State Switch - Circuit Short to Ground
B162C - 12
Tailgate State Switch - Circuit short to Battery or Open Circuit
B1601 - 11
Bonnet State Switch - Circuit Short to Ground
B1601 - 12
Bonnet State Switch - Circuit short to Battery or Open Circuit
B160F - 11
Driver Door Lock Signal - Circuit Short to Ground
B160F - 12
Driver Door Lock Signal - Circuit short to Battery or Open Circuit
B1610 - 11
Driver Door Unlock Signal - Circuit Short to Ground
B1610 - 12
Driver Door Unlock Signal - Circuit short to Battery or Open Circuit
B1630 - 62
Driver Door Lock/Unlock Signal - Signal Compare Failure
B160A- 14
Door Second Stage Unlock/ Door Unlock control others Relay - Circuit short to Ground
B160A- 12
Door Second Stage Unlock/ Door Unlock control others Relay - Circuit short to Battery
B2501- 12
Horn Relay - Circuit short to Battery
B1609 - 14
Door Lock Relay - Circuit Short to Ground or Open
B1609 - 12
Door Lock Relay - Circuit Short to Battery
U100F - 11
Ignition Power mode Input - Circuit Short to Ground
U100F - 12
Ignition Power mode Input - Circuit Short to Battery
U1000 - 11
Accessory Power mode Input - Circuit Short to Ground
U1000 - 12
Accessory Power mode Input - Circuit Short to Battery
U1010 - 11
Key In Signal - Circuit Short to Ground
U1010 - 12
Key In Signal - Circuit Short to Battery
U100E - 11
Crank Power mode Input - Circuit Short to Ground
U100E - 12
Crank Power mode Input - Circuit Short to Battery
U100E - 23
Crank Power mode Input – switch stuck low
B1F00 – 11
Accessory Delay Signal – Circuit Short to Ground
