ELECTRICAL
174
B2247–15
Right Position Lamps – Short to Battery or Open Circuit
B221F–11
Left Front Fog Lamp - Circuit Short to Ground
B221F–15
Left Front Fog Lamp Circuit – Short to Battery or Open Circuit
B2242–11
Right Front Fog Lamp Circuit – Short to Ground
B2242–15
Right Front Fog Lamp Circuit – Short to Battery or Open Circuit
B2227–11
Left Stop Lamp Circuit – Short to Ground
B2227–15
Left stop Lamp Circuit – Short to Battery or Open Circuit.
B224A–11
Right Stop Lamp Circuit – Short to Ground.
B224A – 15
Right stop Lamp Circuit – Short to Battery or Open Circuit
B225E – 11
Left Reverse Lamp Circuit – Short to Ground.
B225E – 15
Left Reverse Lamp Circuit – Short to Battery or Open Circuit.
B225F – 11
Right Reverse Lamp Circuit – Short to Ground
B225F – 15
Right Reverse Lamp Circuit – Short to Battery or Open Circuit
B2229 – 11
Left Turn Indicator – Short to Ground.
B2229 – 15
Left Turn Indicator – Short to Battery or Open Circuit
B224C – 11
Right Turn Indicator – Short to Ground.
B224C – 15
Right Turn Indicator – Short to Battery or Open Circuit
B2229 – 1D
Left Turn Indicator – Circuit Current out of range.
B224C – 1D
Right Turn Indicator – Circuit Current out of range.
B2216 – 1D
Hazard Indicator Lamp – Circuit short to Ground
B225C – 09
Combination Switch Failures (Lights) – Component Failures
B225D – 09
Combination Switch Failures (Wipers) – Component Failures.
B2260 - 11
Left Daylight Running Lamp - Circuit Short to Ground.
B2260 – 15
Left Daylight Running Lamp – Short to Battery or Open Circuit
B2261 – 11
Right Daylight Running Lamp - Circuit Short to Ground
B2261 – 15
Right Daylight Running Lamp - Circuit Short to Battery or Open Circuit
B222E - 11
Main Beam Switch - Circuit Short to Ground
B222E - 12
Main Beam Switch - Circuit short to Battery or Open Circuit
B2503 – 11
Reverse Gear Selection Switch - Circuit short to Ground or Open Circuit
B2503 – 12
Reverse Gear Selection Switch - Circuit short to Battery
B220A – 23
Front Fog Lamp Control Switch – Signal Stuck Low
B220A – 11
Front Fog Lamp Control Switch – Short to Ground
B220A – 12
Front Fog Lamp Control Switch – Short to Battery or Open Circuit
B2225 – 11
Left Rear Fog Lamp Circuit – Short to Ground
B2225 – 15
Left Rear Fog Lamp Circuit – Short to Battery or Open Circuit
B2252 – 62
Turn Indicator Switch – signal compare failure
B2217 – 23
Hazard Switch – Signal Stuck Low
B2239 – 23
Rear Fog Lamp Control Switch – Signal Stuck Low.
B2239 – 11
Rear Fog Lamp Control Switch – Short to Ground.
B2239 – 12
Rear Fog Lamp Control Switch – Short to Battery or Open Circuit
B222D - 11
Low Beam Switch - Circuit Short to Ground
B222D - 12
Low Beam Switch - Circuit short to Battery or Open Circuit
