ELECTRICAL
93
TELL TALES
COLOR
INDICATOR
REMARKS
Diesel Pre-
Heat/Glow
pluge indicator
Amber
Illuminates momentarily when ignition is switched ‘ON’ to
indicate that the glow plugs are active. It will continuously
illuminate when engine is getting preheated. Start the
engine only after the indicator goes off.
Turn Signal
Green
Indicates direction indicated by the turn signal. Blinks
along with buzzer while operating left/right turn indicator
only when ignition is switched ‘ON’.
High Beam
Blue
Illuminates when the high beam headbulbs are switched
ON or flashed.
Front Fog
Green
Illuminates when front fog bulbs are switched ‘ON’.
Rear Fog
Amber
Illuminates when rear fog bulbs are switched ‘ON’.
Low Oil
Pressure
Red
1. Illuminates momentarily when ignition is switched ‘ON’.
2. Illuminates continuously if engine oil level is less than a
pre-defined minimum level. Stop the vehicle as soon as
safety permits and switch off the engine. Check engine oil
level and top-up if required. Contact qualified TATA
MOTORS assistance before starting the engine.
Battery
charging/
engine warning
Red
Illuminates momentarily when ignition is switched ‘ON’
once
is cranked, it goes OFF.
It will continuously illuminate when there is malfunction of
charging system. Contact TATA MOTORS Authorized
Service Centre
Park Brake
cum Low
Brake
Fluid/ABS or
EBD
Malfunction.
Red
1. Illuminates momentarily when ignition is switched ‘ON’
once engine is cranked, it goes OFF.
2. When brake fluid level is low.
3. When park brake is applied and goes OFF when it is
released
4. When ABS/EBD system has a fault.
Seat belt
warning
Red
Indicates that seat belt is not fastened when ignition is
‘ON’. It will flash along with buzzer for 6 secs when ignition
is switched ‘ON’ and seat belt is not fastened. It will
continue to flash until the car exceeds a speed of 20
kmph. After that, it will remain continuously ON along with
a buzzer that will be audible for approx. for100 secs. Then
buzzer goes OFF but the indicator continues to remain ON
until seat belts are fastened.
