C635 TRANSAXLE
31
541258902605 - Installer, Drift
For the Input shaft bearing race (3) use below
Tools
264058903511 - Driver Handle, Universal
541258902604 - Installer, Drift
5. Remove Bearing Race Plate.
6. Install the differential.
7. Install the bearing race plate and tighten the
bolts in four steps using the sequence shown:
Step 1 - Tighten bolts 9-10-6-8-1 to 20 N·m
(15 ft. lbs.) in order.
Step 2 - Tighten bolts 3-5-4 to 25 N·m
(18 ft. lbs.) in order.
Step 3 - Tighten bolts 2-7 to 80 N·m
(59 ft. lbs.) in order.
Step 4 - Tighten bolts 9-10-6-8-1 to 80 N·m (59 ft.
lbs.) in order.
