P1239 - 09:- BMS_BMUFault - Component Failures
Overview:
ISO Code
P1239 - 09
Customer Symptom
Vehicle will not crank
Fault Effects (On Vehicle)
No drive
No charging
Lamp Status (If Any)
HV fault on cluster
Fault occurrence scenario
(In the order of probability)
Any operation
Normal Operating Condition
No fault
Probable Trouble Area
Internal to the battery pack.
Healing Condition
NA
System Details:
Battery management unit hardware is located internal to the pack and communicates internal to the pack.
Preliminary Checks:
1)
Ensure the vehicle is parked, not in charging and that the vehicle is in ignition ON condition
2)
Check the LV battery voltage. It should be atleast greater than 10V.
3)
If LV battery is discharged fully below 10V, ensure to charge back the LV battery to >12V as per
respective standard procedure and re-install on vehicle.
Inspection Method:
Connect the tool and communicate to the battery pack as instructed through APPENDIX-C
Read DTC information of DTC ID –
P1239 - 09
Rectification Action:
1)
If DTC is appearing in real time, clear DTC information through service tool
2)
If DTC is not appearing in real-time but has only occurred before, store the snapshot data. store the
snapshot data.
3)
Clear the DTC information on the respective DTC ID.
DTC’s confirmation:
After clearing, ensure the following points by referring to BMS DTC list.
1)
Read DTC ID –
P1239 – 09
for the existence of DTC information.
2)
If DTC still exists, reflash the battery pack using the service tool with the latest release SW available
in PLM database.
3)
Read DTC ID –
P1239 – 09
for the existence of DTC information post flashing.
4)
If DTC still exists, the HV battery pack component has to be replaced as instructed by the respective
ECU replacement guide
Component Location & Image;Connector Location; Connector View & Information: -
