NEXON EV

X114H: DTC Troubleshooting Document for BMS

Version: 3.0

Date: 01

th

July 2020

Copyright © TATA MOTORS Ltd.

This document must not be used in anyway, such as copying and redistributing to third parties, without the consent of author.

P1235 - 13:- BMS_NegMainRlyConglut - circuit open

Overview:

ISO Code

P1235 - 13

Customer Symptom

Vehicle cannot be cranked

Fault Effects (On Vehicle)

No drive

No charging

Lamp Status (If Any)

HV Fault alarm

Fault occurrence scenario

Any operation

Normal Operating Condition

No fault

Probable Trouble Area

Negative contactor inside battery pack

Healing Condition

NA

System Details:

Negative contactor is located on high voltage side inside the battery pack and its ON/OFF status will be

populated in diagnostics through DID parameter

3404

. Negative contactor is supposed to work

throughout the battery life.

Preliminary Checks:

1)

Ensure the vehicle is parked and not in charging

2)

Ensure that the vehicle is in ignition ON condition

Inspection Method:

Connect the tool and communicate to the battery pack as instructed through APPENDIX-C

Read DTC information of DTC ID –

P1235 - 13

Rectification Action:

1)

If DTC is appearing in real time, clear DTC information through service tool

2)

If DTC is not appearing in real-time but has only occurred before, store the snapshot data. store the

snapshot data.

3)

Clear the DTC information on the respective DTC ID.

DTC’s confirmation:

After clearing, ensure the following points by referring to BMS DTC list.

1)

Read DTC ID –

P1235 – 13

for the existence of DTC information.

2)

If DTC still exists, reflash the battery pack using the service tool with the latest release SW available

in PLM database.

3)

Read DTC ID –

P1235 – 13

for the existence of DTC information post flashing.

4)

If DTC still exists, the HV battery pack component has to be replaced as instructed by the respective

ECU replacement guide.

Component Location & Image;Connector Location; Connector View & Information: -

APPENDIX-A
