485 / 801
BODY
41
6. Remove two upper mounting bolts on C piller
BIW panel.
7. Remove centre seat belt mounting bolts shown
in figure.
8. Remove the rear seat belt assembly.
FITMENT
For fitment follow reverse procedure of removal.
4.27. “A” PILLAR TRIM
•
“A” PILLAR UPPER TRIM
REMOVAL
1. Remove door beading at A Pillar trim location.
2. Pull A Pillar trim from upper locater.
3. Pull “A” Pillar trim bottom snaps from slots.
4. Remove ‘A’ pillar trim.
FITMENT
For fitment follow reverse procedure of removal.
