BODY
40
2. Loosen and remove the lower mounting bolt of
seat belt.
3. Remove front seat belt anchor mounting bolt.
4. Remove lower “B” pillar trim. (For procedure
refer “B” pillar trim removal procedure in Body
section.)
5. Loosen and remove the ELR mounting bolt.
6. Remove the front seat belt assembly.
FITMENT
For fitment follow reverse procedure of removal.
4.26. REAR SEAT BELT
REMOVAL
1. Remove parcel shelf.
2. Remove rear seat backrest (for removal
process refer rear seat removal process).
3. Flip the cushion assembly.
4. Remove rear seat belt bottom mounting
fastener.
5. Remove the bottom mounting fastener & C
pillar upper and lower trim. (For procedure refer
C pillar removal process.)
