NEXON EV SERVICE MANUAL

BODY

4.25. FRONT SEAT BELT

•

FOR RETRACTOR PRETENSIONER LOAD

LIMITER (RPLL)

REMOVAL

1. Fold the front seat to have easy access for the

belt removal.

2. Loosen and remove the lower mounting bolt of

seat belt.

3. Pull out show in fig

4. Remove front seat belt anchor mounting bolt.

5. Remove lower “B” pillar trim. (For procedure

refer “B” pillar trim removal procedure in Body

section.)

6. Disconnect the electrical connection of RPLL.

7. Loosen and remove the RPLL mounting bolt.

8. Remove the front seat belt assembly.

FITMENT

For fitment follow reverse procedure of removal.

•

FOR EMERGENCY LOCKING RETRACTOR

REMOVAL (ELR)

1. Fold the front seat to have easy access for the

belt removal.
