BODY
47
4.36. GLASS
FIXING OF WIND SCREEN GLASS & TAIL GATE
GLASS
The glasses are directly pasted to sheet metal
flanges using sealant. We give below the
Equipment / materials required and the procedure
for fixing the Wind screen and Backlight glasses.
•
EQUIPMENTS REQUIRED:
1. Pneumatic applicator gun with holding
arrangement for sealant cans.
2. Vacuum cups for holding glasses.
3. Tensioner Belt for holding Rear Quarter Fixed
glass.
SR.NOPreparation on Glass (Windshield and Tail
Gate Glass)
Preparation on Body shell
1
Clean the glass with cleaner Betaseal 43518.
Allow it to dry completely.
Assemble the rubber mould to the glass.
Clean the Body shell flange area conforming to
glass with Cleaner Betaseal 43518. Allow it to
dry completely.
2
Apply a thin and even (Approx. 0.5 mm thick
wet layer) of Primer Betaseal 43520A on Allow
it to dry for minimum 2 minutes.
Apply a thin and even coat (Approx. 0.5 mm
thick wet layer) of Primer Betaseal
glass.43533AT on painted surface. Allow it to
dry for minimum 2 minutes.
3
Fill up the mould groove with Sealant Betaseal
58702 with the applicator gun.
(This sealant at later stage spreads on glass
and mating shell flange area, when glass is
fixed.)
