1.5L REVOTORQ BS VI ENGINE
103
B. CLOSED
COUPLED
CATALYTIC
CONVERTER
REMOVAL
1. Loosen and remove the mounting fasteners of
the exhaust front pipe to LNT+DPF.
2. Remove the mounting bolt of the LNT+DPF
support bracket mounted on the engine.
3. Remove the air filter to access the LNT+DPF
mounting to TC on vehicle.
(For Removal
procedures refer Air filter removal).
4. Disconnect the electrical connection and
remove the sensor connector from support
bracket.
5. Remove the support brackets.
6. Disconnect DPF sensor hoses.
