1.5L REVOTORQ BS VI ENGINE
99
27. Disconnect the fuel lines and back leak hose
and them set aside.
28. Disconnect the gear shift cable and selector
cable from the transaxle.
29. Disconnect the hydraulic clutch high pressure
line from the transaxle slave cylinder.
30. Remove the splash guard. (
Refer Body
section for procedure
)
.
31. Remove both front tyres.
32. Remove the left and right drive shafts from
the vehicle.
(For removal procedures refer
Transaxle section).
33. Use suitable belt/chain to fix a zip crane to the
engine lifting hooks located at front and rear
of the engine.
34. Raise the crane slightly up until very light
pressure is applied to the engine.
35. Loosen and remove the 2 mounting nuts and
one bolt on engine 'B' mount assembly.
