1.5L REVOTORQ BS VI ENGINE
108
C. THERMOSTAT
REMOVAL
1. Drain the coolant. (Refer "Coolant
Replacement Procedure).
2. Disconnect the battery terminals.
3. Remove the battery.
4. Remove the battery tray.
5. Set the engine wiring harness and fuel lines
aside.
6. Remove the spring band clip and disconnect
the radiator hose of the thermostat.
7. Remove the mounting bolts and set aside the
EVRV along with the bracket.
8. Remove the thermostat cover.
9. Remove the thermostat assembly from the
water box housing.
FITMENT
For fitment follow removal procedure in reverse.
