FITMENT
For fitment follow reverse procedure of removal.
GLASS PANEL ADJUSTMENT
FRONT
Adjust the front of the glass panel by loosening
the three (3) M5 screws on the either side. Adjust
the glass panel so the front edge is between 1mm
higher or flush with the roof ring and tighten the
screws.
1.4.49 REAR GLASS PANEL (FIXED PANEL)
REMOVAL
1. Position the Front Glass panel in the Close
position. Open Rollo to complete open
position. Press down inner sealing with finger
to expose the screw.
2. Remove the two (2) M5 screws both the sides
on the glass panel Bracket. Remove glass
panel from the vehicle.
FITMENT
For fitment follow reverse procedure of removal.
GLASS PANEL ADJUSTMENT REAR
Adjust the Rear glass panel by loosening the two
(2) M5 screws on the either side. Adjust the glass
panel so the front edge is between 1mm higher or
flush with the roof ring and tighten the screws.
