BODY

52

1.4.42 REAR WHEEL ARCH LINER



REAR WHEEL ARCH FRONT

REMOVAL

1. Remove clip push button of front cladding,

fender.

2. Pull out the cladding fender.

3. Remove mounting Clip Rear wheel arch liner

front.

4. Remove Push on Nuts as shown in figure.

5. Remove three Rear Bumper mounting screw.

6. Remove Rear wheel arch front.

FITMENT

For fitment follow reverse procedure of removal.
