NOTE
While pulling out the tail gate trim, care should be
taken such that tree clips do not get damage.
Below image gives location of tree clips on tail
gate trim.
FITMENT
1. Match Tailgate trim buttons properly with the
hole.
2. Press trims gently, ensure its proper fitment.
1.4.21 ORVM
REMOVAL
1. Pull out inside cover plate along with Power
mirror switch.
2. Disconnect power mirror switch.
3. Disconnect the electrical connection
4. Loosen and remove 2 mounting screws
