5. Disconnect the window winding connection
and remove the switch.
6. Pull out inner handle cap
7. Loosen and remove the mounting screw of
inner handle.
8. Insert plastic wedge pin and remove the door
trim.
FITMENT
For fitment follow the reverse procedure of
removal.
1.4.17 REAR OUTER DOOR LOCK
REMOVAL
1. Remove the rear door trim.
(For procedure
refer rear door trim removal process which is
same as that of front door trim removal.
)
2. Remove the mounting screw of rear door lock.
3. Remove the lock barrel.
4. Slide the gripper handle at back.
