BODY
34
6. Disconnect the inner handle cable from the
door inner lock handle.
7. Loosen and remove three door latch mounting
screw.
8. Disconnect outer handle link from the handle
end.
9. Remove the latch.
FITMENT
For fitment follow reverse procedure of removal.
1.4.19 TAIL GATE
REMOVAL
1. Open the tail gate.
2. Remove rear Quarter trims (for removal
process refer rear Quarter trims removal
process).
3. Remove rear ‘C’ Pillar trims (for removal
process refer rear ‘C’ Pillar trim removal
process).
4. Disconnect the tail gate all wiring harness
located inside the “C” pillar trim and pull out
the wiring harness from outside.
5. Remove the top hinge mounting of the tail gate
by removing two mounting bolts. Follow the
same procedure at the other end and separate
the tail gate from the vehicle.
