TAIL GATE LOCK
REMOVAL
1. Remove the tail gate trim.
2. Disconnect the connection between latch and
the Lock Barrel.
3. Remove the mounting Hex Screw and Pull
out the tail gate lock from outside.
FITMENT
For fitment follow reverse procedure of removal.
NOTE
Check the condition of the tailgate lock. Replace
the lock if broken or damaged.
1.4.20 TAIL GATE TRIM
REMOVAL
1. Open the tail gate.
2. Pull out the two mounting clip and highlighter
trims.
3. Remove and pull out the tail gate wiper motor
cover.
4. Pull out tailgate trim by plastic wedge / fingers
and pull out trim gently.
