446 / 1003
TRANSAXLE TA6300
32
Once the bearing comes out, unlock the
anchoring shaft by turning the locking nut
anticlockwise on the top and slowly tap on the
locking stud down to unlock the bearing from
anchoring body and to remove bearing from
the tool.
23. Remove Oil Feeder Lay shaft.
24. Remove cylindrical roller bearing of Input
shaft from front housing with the help of puller
5438 5890 2618.
PROCEDURE FOR REMOVAL OF INPUT
SHAFT BEARING
Position the transaxle RH side case, facing the
bearing in upward direction.
Take the bearing puller (5438 5809 2618) and
place the outer hub of puller on the machined
surface of transaxle casing, surrounding of the
input shaft bearing.
Rotate the pulling nut 30 mm anticlockwise and
allow anchoring body shaft of puller to get
inserted inside the bearing.
Once the anchoring body is inserted fully, hold
the locking stud on the top using open end
spanner 8 mm and turn the locking nut on the
top slowly using open end spanner 17 mm, few
turns till it gets resistance to rotate.
