TRANSAXLE TA6300
30
19. Remove the differential assembly along with
taper roller bearing from the housing front.
20. Remove oil seals of drive shaft from housings.
Replace it with a new one while
assembling.
21. Remove Outer race taper bearing of
differential from front housing & rear housing
with the help of puller 5438 5980 2603.
22. Remove cylindrical roller bearing of lay shaft
from front housing with the help of puller 5438
5980 2617.
PROCEDURE FOR REMOVAL OF LAY OR
COUNTER SHAFT BEARING
Position the transaxle RH side case, facing the
bearing in upward direction.
