TRANSAXLE TA6300
25
23. Loosen and remove B Mount Bracket. With
rubber pad.
24. Remove clutch housing mounting bolts.
25. Finally take out Gear box Assembly from
vehicle.
INSTALLATION:
Follow the reverse procedure of Assembly of
Transaxle on Vehicle
.
10. REMOVAL OF TRANSAXLE FROM
VEHICLE (DIESEL):
1. Position the vehicle properly on the two-post
lift.
2. Disconnect the battery terminals.
3. Remove Battery mountings & take it out.
4. Remove Battery Tray.
5. Remove ECU connection.
6. Lift the vehicle on using two-post lift and
remove the front wheels LH & RH.
