TRANSAXLE TA6300
23
9. REMOVAL OF TRANSAXLE FROM
VEHICLE (PETROL):
1. Position the vehicle properly on the two-post
lift.
2. Disconnect the battery terminals.
3. Remove Battery mountings & take it out.
4. Remove Battery Tray.
5. Remove ECU connection.
6. Lift the vehicle on using two-post lift and
remove the front wheels LH & RH.
7. Drain the Transaxle oil through Drain Plug.
8. Remove earthing cable from gear box.
9. Remove stub axle ball joint Mounting &
Loosen Lower Control Arm on LH & RH side.
10. Remove driveshaft lock nut LH& RH.
