1.5L REVOTORQ ENGINE
57
vi. DRAINING WATER FROM FUEL FILTER
1. Stop the engine allow the pressure to
stabilize.
2. Disconnect the electrical connection of the
drain water sensor and also disconnect one
of the fuel lines either inlet or outlet.
3. Keep a suitable container to collect the
drained water.
4. Rotate the drain water sensor in anti-
clockwise direction for about 2 turns and
allow approximately 120cc of diesel to drain
and then tighten the sensor.
(Tightening Torque: 1.4 ± 0.2 Nm)
5. Reconnect the fuel line and electrical
connection that was disconnected.
6. Drain the water from the fuel filter bowl during
every service.
vii. AC COMPRESSOR, ALTERNATOR BELT
REPLACEMENT
REMOVAL
1. Lift the vehicle and remove the RH side front
mud liner.
(For procedure refer body section).
2. Insert the alternator belt removal special tool
(part no. 5427 5890 0602)
as shown and
rotate the crankshaft pulley in clockwise
direction to pop out the belt; then remove the
alternator belt.
