1.5L REVOTORQ ENGINE
53
METHOD 2
1. Vehicle condition And Parking.
Park the vehicle on flat level surface.
Allow the vehicle to cool down to workable
temperature
(preferably
to
ambient
temperature).
Place ta clean tray just below the drain plug
located at bottom of radiator.
2. Drain coolant from radiator.
Open the pressure cap & drain plug and
allow the coolant to drain out into the
container.
Blow in the pressurized air through pressure
cap opening till all the coolant is drain out &
close pressure cap.
3. Remove coolant from water pump, heater and
cooling system hoses.
Open the heater top hose & blow
pressurized air in the heater top hose
thermostat side (block the heater inlet part
towards heater coil with the help of plug).
Repeat same operation in reverse direction
(heater inlet towards heater coil side air will
be blown & thermostat side will be closed).
Connect the heater top hose. Close the
drain plug.
4. Initial coolant filling through pressure cap
opening.
Opening EGR hose and top hose of heater
core.
Filling coolant through pressure cap
opening till coolant is visible in the EGR
hose. Refit EGR hose.
Keep filling coolant till coolant is visible in
the heater hose. Refit the heater hose.
Fill the no loss tank till the max level.
5. Start the engine and maintain engine 3000
rpm.
Close the pressure cap & start the engine in
idle condition for a few seconds. Rev up &
maintain engine speed at 3000±100 rpm.
Radiator fan switch ‘ON’ for the first time
once coolant temperature reaches the fan
trigger threshold.
Continue the de-aeration process until
completion of two heat cool cycles of
radiator fan (i.e. Radiator fan turns ‘ON’ &
‘OFF’ for two times).
Allow engine to cool down until coolant
temperature reaches ambient temperature.
6. Fill coolant after vehicle cool down.
After cool down, observe drop in coolant
level in no loss tank & if required fill coolant
until max mark.
Also open pressure cap & fill coolant till the
neck is full if required.
De-aeration process is now complete.
