1.2L REVOTRON ENGINE
102
FUEL FILLER NECK ASSEMBLY AND
BREATHER HOSE
REMOVAL
1. Place the vehicle in a 2 poster lift.
2. Refer precautions and relive fuel pressure.
3. Remove the fuel filler cap.
4. Remove the fuel filler cover to access the fuel
filler neck assembly mounting bolts.
5. Disconnect fuel lid cable from fuel lid lever and
pull it out from the luggage compartment.
6. Loosen and remove the fuel filler neck
assembly mounting fasteners.
7. Unscrew the fastener at filler neck support
bracket.
8. Remove the fuel filler and breather hose
clamps from filler neck end.
