1.2L REVOTRON ENGINE
132
12. Assemble the engine Timing Cover.( Refer
the tightening sequence)
13. Assemble the crankshaft front oil seal.
14. Assemble crankshaft Pulley.
NOTE
Ensure the flywheel in lock position during
crankshaft pulley assembly.
15. Assemble the Alternator, Compressor, and
Water pump.
16. Assemble the water pump pipe and seal by
using special tool.
SPECIAL TOOL
Tool-Water pipe installation:-
5424 5890 20 02
